Oil Mold Controller Type 210 H6/12E SISE SAS

Oil Mold Controller Type 210 H6/12E

Temperature regulator for plastic

Vote

VGhlIG1vbGQgY29udHJvbGxlcnMgJm5ic3A7b2YgdGhlIDIxMCBINi8xMkUgcmFuZ2Ugb3BlcmF0ZSB3aXRoIG9pbCB1cCB0byBhIHRlbXBlcmF0dXJlIG9mIDIxMCZkZWc7QyBvciAyNTAmZGVnO0MgKG9wdGlvbikuICZuYnNwOyAmbmJzcDtUaGUgdGVtcGVyYXR1cmUgY29udHJvbGxlcnMgYXJlIGVxdWlwcGVkIHdpdGggYSA2MEwvbWluLi4u

“ Anti cracking system. Heating resistors don't have any contact with oil int he boiler which avoids accelerated deterioration of the oil. ”
Contact the supplier Receive Documentation Ask for a quote

OTHER PRODUCTS FROM SISE SAS

Check out all the products from SISE SAS

USERS WHO SAW THIS ALSO VIEWED


The mold controllers  of the 210 H6/12E range operate with oil up to a temperature of 210°C or 250°C (option).

 The temperature controllers are equipped with a 60L/min magnetic coupling pump with max 5 bars of pressure, a heat plate exchanger (spiralled) and offers 6 or 12kW of heating power.

Control is ensured by a self-tuning microprocessor controller.

The heaters have no contact with the oil in the tank, which prevents accelerated deteriation (cracking).  Addtionally these and other parts are easily replaceable (emptying is not necessary), resulting in facilitated maintenance.

The controller can communicate with the press via several protocols, including Modbus, Profibus, TTY, RS485, SPI…
Options include flow meters, remote communication, manual bypass, solid state relay and custom colors, among others.

Versions equipped with machine communication capability can directly download mold data and alarm signals from the injection molding machine control panel.

Applications :

All high temperature applications that require a heating power of up to 12kW (mid-sized molds, dual-layered tanks, calendering, heating tables, relatively fast rise in temperature, control of fluid process for chemical, petrochemical, and pharmaceutical industries, and  particular temperature conditions.

Maximum Temperature : 210°C or 250°C optional Heating Capacity : 6 or 12 kW Cooling Technology : Plate heat exchanger Pump type : Magnetic coupling Maximum Throughput : 60 L/Min Maximum Pressure : 5 bars Voltage : 400V - 3Ph. + E - 50Hz Control and regulation : Microprocessor, self-tuning Filling : Manual, volume 15 L Cooling power : 45 kW (Water 10°C - Process T°C max)
