RS1280 high-resolution LWIR uncooled portable thermography camera

RS1280 high-resolution LWIR uncooled portable thermography camera - INNOVIDEA

RS1280 high-resolution LWIR uncooled portable thermography camera - Thermal infrared cameras

RS1280 high-resolution LWIR uncooled portable thermography camera

Thermal infrared cameras

“ - portable LWIR thermography camera with high resolution 1280x1024 and high sensitivity 25mK - ergonomic design and intuitive interface under Android - complete software (report generation in pdf, AI) ”

Ask for a quote

RayThink's RS1280 high-resolution LWIR uncooled portable thermography camera uses a 1280×1024 pixel Vox microbolometer with 12µm pitch, complemented by a 13 Mpixel visible CMOS, and offers high sensitivity with a NETD of 25mK.
It is particularly well suited to applications in scientific research, non-destructive testing and industrial environments (energy, semiconductors & microelectronics, etc.)

With its ergonomic design, rotating handle and standard 34.9mm optics (25°x20° field of view), plus a 5.5" full HD OLED display with adjustable orientation, the RS1280 is available with several scene temperature calibration ranges: -20°C to +150°C, +150°C to 800°C and optional +400°C to +1500°C.

Its Android-based software features include supra-resolution at 2560x2028, 16-bit digital images stored on a native 62GB SD card (SDXC 2TB optional), up to 35 different simultaneous analysis zones, and artificial intelligence algorithms.

Compliant with CE and RoHS standards, with 3 hours of continuous use (rechargeable lithium-ion battery), the RS1280, with its IP54 enclosure, 1.7kg weight and 140×210×115mm footprint, is easy to transport, and can quickly produce a pdf measurement report that can be exported via Wifi, Bluetooth or USB 3.0.

Technical features

- high-resolution LWIR camera 1280x1024 pixels with 12µm pitch - temperature ranges: -20°C to +150°C, +150°C to 800°C - high sensitivity with Vox microbolometer - NETD 25mK - Android software - functions: super-resolution, 35 analysis zones, report editing pdf - standard optics 34.9mm (25°x20°) - other options 19.8mm, 72.9mm - 5.5 - IP64 enclosure - 3h operating time - rechargeable Lithim-ion battery

Download the complete technical features
