E2Prox-640, USB-C UVC interface board for LWIR ATI640 module

“ - Solution compatible with ATI640 shutterless LWIR module - Use with standard video players (no special software required) - USB-C UVC output for I2C, UART or virtual port com protocols ”

Ask for a quote

Presentation

The E2Prox-640 USB-C UVC interface board from E2I Solutions has been developed specifically for the Lynred ATI640 family of shutterless LWIR thermal modules with 640x480 pixel microbolometer at 12µm pitch.

It converts the native MIPI-CSI2 output to USB-C UVC and is compatible with YUV422, RAW8 and RAW12 input signals

The USB-C UVC output allows the user to use either the I2C or UART protocol, or to create a virtual com port

The E2Prox-640 is particularly suited to users wishing to use ATI640 modules without optics, or equipped with 25mm, 13mm or 7.5mm optics with high-performance NETD and integrated denoising (less than or equal to 24mK) and can be used for various application.

Its design is adaptable; please consult us.

Technical features

Card with USB-C UVC output compatible with VGA LWIR ATI640 modules Complements ATI640 without or with optics (25mm, 13mmm, 7.5mm) Conversion of YUV422, RAW8, RAW12 input signals Output as I2C, UART or virtual port com Dimensions: 23.8x23.8X10mm External trigger function included Weight: 5g Power consumption : 400mW alone - 1,45W with ATI640D

Download the complete technical features
